| Modle: |
COMPTON-610 Chip-in Ceilings System |
|
|
|
|
| description: |
Clip-in type ceiling featuring simple and pretty appearance with suspended system is easy to install and dismantle to meet the requirements of space and flexibility. It has different models which can be applied in different architectural designs.
Grid ceiling system with additional components can work with lighting and draft apparatus; sound insulation cotton can be designed to improve sound-absorbing function; surface plate and jack panel are optional. Jack panel with different portiforium proportion and pattern can meet different requirements.
|
| Main Keel: |
29mm high, 29mm wide, 2.0mm thick, with different side of the keel on both sides of the punching module to facilitate the installation and adjustment of material for hot-dip galvanizing steel. |
| Ancillary Keel: |
38.6mmx16mm, material for hot-dip galvanizing steel. |
| Panel: |
Thickness of 0.8mm, width of 300mm, 600mm, a length of 300mm, 600mm, 1200mm, material for the 3003 aluminum alloy, surface treatment for powder coating. |
| Color: |
The color can be chosen with reference to the color swatch cards Compton offers. |
| Suspension rod system: |
φ 6mm or φ 8mm screw rod. |
| Perforation: |
φ 2.3mm (with Germany Soundtex sound muffling non-woven fabrics on the back). |
| Integrated system: |
It is proposed that the lighting and air-conditioning should be at the same level of ceiling, or the lighting be installed under the ceiling separately. |
| Minimum clearance: |
300mm |
| Interval of keel: |
Middle 1200mm, wall 400mm pitch |
| Interval of the suspension rod: |
1200mmx1200mm |
|
|
|
